Chlorosulfonated Polyethylene
21/04/22 10:28:04
Product Applications
1,Rubber hoses
Automotive power steering hose, oil filling hoses, cooling hoses for gear-box oil, anti oil hoses.
2,Wire and cable
With excellent wear resistance, heat resistance, low water absorption, sun resistance, ozone resistance, corona resistance, CSM can be used as wire and cable jacket;
Under high temperature, with good color stability and UV resistance, it can also be used to produce color wire and cable jacket variety different applications. Wire and cable jacket made of CSM meet the standards of IEEE and it is already used in nuclear stations, special cables like electrical and arc resistance cables, locomotive cable, rail transit cables, wind energy cables, electric vehicle charging cables.
3,CSM rubber cloth
With excellent heat aging resistance, ozone resistance, weather ability, high temperature and low temperature resistance and flame retardant properties, CSM can be used as shed fabric for rail train,bus train.
In rubber cloth fields, CSM is also used in large quantity, including bridge cable rubber binding strap, yacht rubber cloth, inflatable dinghy rubber cloth, outdoor tent, inflatable pool, oil fence, bus wind shield cloth, building roof waterproof material, protection mat in power plant.
4,Adhesive
In the field of adhesives, CSM free radical curing adhesive compositions excel in improving the peel strength between substrates.
Applicable for adhesion between metal and rubber, metal and thermosetting resin, plastic and plastic;
Applicable for adhesion between PPS, PP and aromatic nylon;
Applicable adhesion between high strength steel and carbon fibre, or between glass fiber reinforced plastics, carbon steel and carbon fibre, or carbon steel and glass fiber reinforced plastics;
Applicable for adhesion between rubber and polyamide fibers, or glass fiber reinforced Fiber.
5,Rubber rollers
CSM have very good ageing resistance, ozone resistance, chemicals resistance and high temperature resistance properties, which allows it to be used in rubber rollers for printing, paper production and metallurgy.
6,Damping and noise reduction materials
Damping sheets can be used in different equipment structural surface fierce vibration areas ( like marine engine room, base, fan) to control and governance structural noise.
7,Rubber sheets
With excellent resistance to chemicals, ozone, weather, acid, heat and abrasion resistance, it can be used as different rubber rings, rubber cushion and sealing parts, etc.
8,Shoes
With excellent resistance to low temperature and weather, abrasion resistance, flame resistance, durability, high tearing and tensile strength, excellent elasticity, it can be used as sports shoes soles, snowshoes, shoe buckle strip,and other fabric reinforcement rubber cloth.
9,Other
CSM can also be used in elevator handrail belt, synchronous belt, conveyor belt, raincoat, chemical resistant gloves, weather resistant and corrosion resistant coating applications.
SPECIFICATIONS
1,Rubber hoses
Automotive power steering hose, oil filling hoses, cooling hoses for gear-box oil, anti oil hoses.
2,Wire and cable
With excellent wear resistance, heat resistance, low water absorption, sun resistance, ozone resistance, corona resistance, CSM can be used as wire and cable jacket;
Under high temperature, with good color stability and UV resistance, it can also be used to produce color wire and cable jacket variety different applications. Wire and cable jacket made of CSM meet the standards of IEEE and it is already used in nuclear stations, special cables like electrical and arc resistance cables, locomotive cable, rail transit cables, wind energy cables, electric vehicle charging cables.
3,CSM rubber cloth
With excellent heat aging resistance, ozone resistance, weather ability, high temperature and low temperature resistance and flame retardant properties, CSM can be used as shed fabric for rail train,bus train.
In rubber cloth fields, CSM is also used in large quantity, including bridge cable rubber binding strap, yacht rubber cloth, inflatable dinghy rubber cloth, outdoor tent, inflatable pool, oil fence, bus wind shield cloth, building roof waterproof material, protection mat in power plant.
4,Adhesive
In the field of adhesives, CSM free radical curing adhesive compositions excel in improving the peel strength between substrates.
Applicable for adhesion between metal and rubber, metal and thermosetting resin, plastic and plastic;
Applicable for adhesion between PPS, PP and aromatic nylon;
Applicable adhesion between high strength steel and carbon fibre, or between glass fiber reinforced plastics, carbon steel and carbon fibre, or carbon steel and glass fiber reinforced plastics;
Applicable for adhesion between rubber and polyamide fibers, or glass fiber reinforced Fiber.
5,Rubber rollers
CSM have very good ageing resistance, ozone resistance, chemicals resistance and high temperature resistance properties, which allows it to be used in rubber rollers for printing, paper production and metallurgy.
6,Damping and noise reduction materials
Damping sheets can be used in different equipment structural surface fierce vibration areas ( like marine engine room, base, fan) to control and governance structural noise.
7,Rubber sheets
With excellent resistance to chemicals, ozone, weather, acid, heat and abrasion resistance, it can be used as different rubber rings, rubber cushion and sealing parts, etc.
8,Shoes
With excellent resistance to low temperature and weather, abrasion resistance, flame resistance, durability, high tearing and tensile strength, excellent elasticity, it can be used as sports shoes soles, snowshoes, shoe buckle strip,and other fabric reinforcement rubber cloth.
9,Other
CSM can also be used in elevator handrail belt, synchronous belt, conveyor belt, raincoat, chemical resistant gloves, weather resistant and corrosion resistant coating applications.
SPECIFICATIONS
| Item | Chlorine % | Sulfur content % | Volatile matter % | Tensile strength | Elongation at break % | Mooney viscosity | Application |
| MPa | ML(1+4)100℃ | ||||||
| Poly-S403 | 35±2 | 1.0-1.5 | ≤0.5 | ≥25 | ≥450 | 40-50 | Various automobile hoses, such as power steering hose, oil return pipe, refueling oil hose, transmission oil cooling hose, LPG hose, chemical resistance hose; sealing and oil sealing products; special cables, locomotive cables, rail transit cables, wind energy cables, electric vehicle charging cables, submarine cables, radiation protection cables, Marine cables, special rubber rollers, special tape, special rubber sheets, armrest, shoe materials, heat resistant sheath, etc. |
| Poly-S503 | 35±2 | 1.0-1.5 | ≤0.5 | ≥25 | ≥450 | 50-60 | |
| Poly-S603 | 35±2 | 1.0-1.5 | ≤0.5 | ≥25 | ≥450 | 60-70 | |
| Poly-S703 | 35±2 | 1.0-1.5 | ≤0.5 | ≥25 | ≥450 | 70-80 | Various automobile hoses, such as power steering hose, oil return pipe, refueling oil hose, transmission oil cooling hose, LPG hose, chemical resistance hose; sealing and oil sealing products; special cables, locomotive cables, rail transit cables, wind energy cables, electric vehicle charging cables, submarine cables, radiation protection cables, Marine cables, special rubber rollers, heat resistant sheath, etc. |
| Poly-S803 | 35±2 | 1.0-1.5 | ≤0.5 | ≥25 | ≥450 | 85-95 | |
| Poly-S903 | 35±2 | 1.0-1.5 | ≤0.5 | ≥25 | ≥450 | 95-110 | |
| Poly-S604 | 43±2 | 1.0-1.5 | ≤0.5 | - | - | 50-70 | Oil resistant rubber products,fluid resistant rubber Products,Shock-absorbing rubber products |
| Poly-S48 | 43±2 | 1.0-1.5 | ≤0.5 | - | - | 70-90 | Oil resistant rubber products, fluid resistant rubber products; film material,and films produced are hard with gloss and featured with better low-temperature properties. |
| Poly-S45 | 25±2 | 1.0-1.5 | ≤0.5 | - | - | 35-45 | Thermoplastic low-temperature resistant materials without vulcanization; magnetic rubber products, radiation shielding products, high-hardness rubber products, rubber flooring mats, water-proof roofing sealing products, rubber rolls, rubberized fabrics, water-proof rolling materials, binding agents. |
| Poly-S30H | 43±2 | 1.0-1.5 | ≤0.5 | - | - | 25% Viscosity of toluene solution（25°C), mPs*S 1000-2000 | Coating applications, Mixed slurry can be used as textiles coating, adhesive. |
| Poly-S30L | 43±2 | 1.0-1.5 | ≤0.5 | - | - | 25% Viscosity of toluene solution（25°C), mPs*S 400-600 | Coating applications, more applicable for organic solvent,forming a low viscosity and high solid content formula.Mixed slurry can be used as textiles coating, duty anti-corrosion coating,chemicals resistance gloves. |
| Poly-S20 | 30±2 | 1.3-1.7 | ≤0.5 | - | - | 30-40 | Coating applications,ultra-thin rubber cloth, chemicals resistance gloves, adhesive. |
| Poly-HV40 | 35±2 | 1.0-1.5 | ≤0.5 | 45-50 |
CSM Free radical-cured adhesive composition can effectively increase peel strength between base materials. Applicable for adhesion between metal and rubber, metal and thermosetting resin, plastic and plastic; Applicable for adhesion between PPS, PP and aromatic nylon; Applicable for adhesion between high strength steel and carbon fibre, or between glass fiber reinforced plastics, carbon steel and carbon fibre, or carbon steel and glass fiber reinforced plastics; Applicable for adhesion between rubber and polyamide fibers, or glass fiber reinforced Fiber. |
||
| Poly-HV50 | 35±2 | 1.0-1.5 | ≤0.5 | 55-60 |
